Applications

(1) It is widely used in electronic components, battery chargers, electric wire, computer accessories, mobile phone accessories (mobile phone screen, LCD screen) and communication products.

(2) Automobile and motorcycle spare parts, auto glass, instrument appliance, optical device, aerospace, military industry products, hardware machinery, tools, measuring tools, cutting tools, sanitary ware.

(3) Pharmaceutical, food, beverage and cosmetics industry.

(4) Glass, crystal products, arts and crafts of surface and internal thin film etching, ceramic cutting or engraving, clocks and watches and glasses.

(5) It can be marked on polymer material, majority of the metal and non-metallic materials for surface processing and coating film processing, pervious to light polymer materials, plastic, fire prevention materials etc..

Features

3D UV laser marking machine has been upgraded on an ordinary machine and can complete 2D and 3D work, such as engraving cylinders, rings, and curved surfaces.

1. The SINO-GALVO RF8220-3D Dynamic Focusing Galvo Scanning System features excellent operational stability, high positioning accuracy, rapid marking speeds, and strong anti-interference capabilities. During dynamic marking operations, it delivers high line precision, zero deformation, uniform power distribution, and distortion-free patterns; its comprehensive performance metrics meet or exceed the technical standards of comparable domestic and international products. Utilizing an advanced optical design scheme, the system is characterized by minimal light loss, a compact footprint, high positioning accuracy, rapid marking speeds, and robust anti-interference capabilities, making it ideally suited for precision laser processing applications—including marking on flat surfaces, complex curved surfaces, and deep engraving.

2. With the MM3D software system, which supports the importation of various file formats—including vector graphics, bitmaps, text, and barcodes—offering an intuitive interface that is easy to understand and quick to master.

3. Huaray 10W low-power nanosecond UV lasers features a brand-new, "All-in-One" integrated design. The laser unit is rigorously engineered with IP65-rated double-layer sealing, ensuring reliable operation even in environments characterized by high temperatures and high humidity. Its proprietary motorized LBO crystal shifting technology guarantees an extended operational lifespan for the laser source. Furthermore, having successfully passed EMC testing, the unit is impervious to electromagnetic interference; it also holds CE certification, facilitating hassle-free export and global deployment. This laser system is specifically designed to meet the demands of high-speed, precision manufacturing lines while simultaneously ensuring long-term stability and reliability.

4. Supports a maximum marking field of 400 × 400 mm; custom marking field sizes ranging from 100*100 mm to 400 × 400 mm can be configured to meet specific requirements.

5. Incorporates a water-cooling structure to effectively regulate and maintain the operating temperature of the galvanometer scanners.

6. External Auto-Focusing Module: Provides real-time focus measurement to ensure exceptional focusing accuracy. For objects of varying colors, the measurement error is less than 0.2% of full scale (FS)—with the exception of highly reflective materials.

7. With two dimentional working table

8. With long object rotary axis
