Handheld Type Metal Fiber Laser Marking Machine

Brief Introduction:

Model: UG-20FM
Handheld fiber laser marking machine
For metal and part of non-metal marking
20W Raycus



Electronic and communications products, integrated circuit chip, computer parts and electrical appliance,all kinds of precision component,  hardware tool, instrument and meter, aerospace and astronautics, jewelry, horologe, gift, office supply, trademark signs, sanitary ware, kitchen ware, plastic product, metal ornament, fastener, eyeglasses frame, , sanitary ware fittings, tableware, food, beverage and alcohol & tobacco,etc all kinds of area graph and characters’s, marking, mass production, marking clear and beautiful, never disappear.


1.Laser marking head is detachable type, can be handheld marking, suitable for any kinds of angle marking

2. Detachable design & integrated system let user convenient using, can disassemble laser head and handheld marking, good solutions for all kinds of industrial application.

3.Whole fiber structure of laser equipment, ensuring the laser high stability, no need any optical element to do collimation adjusting.

4. Indoor and fields all can use, and easy to carry.

Adopting fiber laser to output laser, high electro-optic conversation rate, compact size, good quality velocity of light. The life time of fiber laser is more than 100,000 hours, if each year working 365 days, each day working 24 hours, then the life time is more than 10 years, are the real maintenance free, saving the later period maintenance cost.

6. Fiber laser marking machine has good facula mode, more thin single line, suitable for hyperfine processing, high system integration, less malfunction, are the real suitable for industrial processing area.

7. Marked graph and characters is permanent , will not regression  due to friction.

8. No consumable, low power consumption, whole air cooling, no need water cooling, total machine power less than 500W

9. Not influenced by severe environment and bag weather, can continue working with accumulator when power failure.

10.Can for bar code, graph, characters, OR code, ect marking, supporting PLT, DXF, BMP such format, can useSHC, TTF word stock; System can auto encoding, auto marking serial number, batch number, and date, ect.

    Maximum output laser power

    20W, Raycus

    Wave length of laser


    Marking scope


    Laser sources

    Fiber module

    Laser Head

    High speed scanning head

    The minimum focus facula diameter


    Minimal character


    Control system

    Original Ez cad controller with USB port

    Marking depth

    0.01-5mm( depends on different materials)

    Marking line width


    Marking speed


    Laser repetition frequency


    Cooling method

    Force-air Cooling

    Power supply

    AC 220V+10%50/60Hz, single phase

    Support format

    PLT, BMP, DXF, JPG, TIF, AI etc

    Process Material

    All kinds of metal and part of Non-metal Materials
